Molding shell,touch keys,microprocessor intelligent control.
-
With automatic memory function.
-
With standard,timing operation function.
-
Automatic detection of no-load,over-load.
Specifications
| FSF300 | FSF600 | FSF300C | FSF600C | FSF300E | FSF600E | FSF1000C | FSF1000E | |
| Type of Output | Constant-Voltage,Current | Constant-Voltage,Current | Constant-Voltage,Current or Power | Constant-Voltage,Current or Power | Constant-Voltage,Current or Power | Constant-Voltage,Current or Power | Constant-Voltage,Current or Power | Constant-Voltage,Current or Power |
| Output range | 5~300V,1~300mA Maximum 90W |
5~300V,1~300mA Maximum 90W |
5~300V,1~400mA 1-120W |
10~600V,1~500mA 1-300W |
1~300V,1~400mA 1-120W |
10~600V,1~500mA 1-300W |
30~1000V,1~500mA 1-300W |
30~1000V,1~500mA 1-300W |
| Increment | 1V,1mA | 1V,1mA | 1V,1mA,1W | 1V,1mA,1W | 1V,1mA,1W | 1V,1mA,1W | 1V,1mA,1W | 1V,1mA,1W |
| Timer Range | 1min~9hr,59min | 1min~9hr,59min | 1min~99hr,59min | 1min~99hr,59min | 1min~99hr,59min | 1min~99hr,59min | 1min~99hr,59min | 1min~99hr,59min |
| Display | LED | LED | LCD display with backlight | LCD display with backlight | LCD display with backlight | LCD display with backlight | LCD display with backlight | LCD display with backlight |
| Output jacks | Two sets of output jacks | Two sets of output jacks | Four sets of output jacks | Four sets of output jacks | Four sets of output jacks | Four sets of output jacks | Four sets of output jacks | Four sets of output jacks |
