Simple operation,only four fastening knobs needed.50％ buffer savings compared with traditional tanks.
-
Unfolded electrodes make repair and parts replacement easy and quick.
-
Specid heat dissipation processed aluminum plate firmly clings to the gel plates,which effectively guarantees the gel temperature is even,ensuring the electrophoresis trip is straighter .
Technical specifications
| Glass plate size(W×L) | Gel Size(W×L) | Gel thickness | Gel amount | Sample volume | Buffer Volume | Dimension(L×W×H) | Net weight | |
| FSF-CX1B | 200×450 mm | 180×420 mm | 0.4mm | 1(pieces) | (0.4mm)50、62、 74、100wells |
~500 ( ml ) | 310×230×500(mm) | 11(kg) |
| FSF-CX2B | 350×450 mm | 330×420 mm | 0.4(mm) | 1(pieces) | (0.4mm)50、62、 74、100wells |
～750（ml） | 455×230×500(mm) | 16.5(kg) |
| FSF-CX3B | 350×350 mm | 330×320 mm | 0.4(mm) | 1(pieces) | (0.4mm)50、62、 74、100wells |
～750（ml） | 460×230×400(mm) | 13.2(kg) |
