Feature
5 program groups, 99 storage slots, quick recall.
Auto electronic lock, one-key short spin.
HD large LCD display and the parameters can be revised during operation without shutdown.
Brushless motor, 10-speed linear acceleration/deceleration.
Two modes can be set: start timing/arrival revolution timing.
10 gears acceleration /deceleration with linear drive.
Rotor ID system, auto-lid lock protection.
Safety: Over speed, overheat, imbalance alerts.
Stainless steel chamber, anti-corrosion coating.
Quick-lock rotor lid.
Main technical parameters
Technical Parameter:
| Model | FDT35C |
| Max Speed | 5500rpm |
| Max RCF | 4675×g |
| Max Capacity | 4 × 250ml |
| Timer | 1s~99h59min59s |
| Revolutions/min | ± 10r/min |
| Voltage | AC 220±22V 50Hz 10A |
| Power | 550W |
| Noise Level | ≤62dB (A) |
| Exterior Size | 430× 540×355 (mm) |
| Net Weight | 45kg |
| Rotor Automatic Identification | Yes |
| Angle Rotor No.1 | Angle Rotor No.2 |
| Max, speed: 5500rpm Max RCF: 3645xg Rotor capacity: 6x50ml |
Max, speed: 5500rpm Max RCF: 4675xg Rotor capacity: 24x15ml |
| Angle Rotor No.3 | Swing-out Rotor No.4 |
| Max, speed: 5000rpm Max RCF: 4191xg Rotor capacity: 40x15ml |
Max, speed: 4000rpm Max RCF: 2951xg Rotor capacity: 4x50ml |
| Swing-out Rotor No.5 | Swing-out Rotor No.6 |
| Max, speed: 4000rpm Max RCF: 2951xg Rotor capacity: 4x100ml |
Max, speed: 4000rpm Max RCF: 2951xg Rotor capacity: 8x50ml |
| Swing-out Rotor No.7 | Swing-out Rotor No.8 |
| Max, speed: 4000rpm Max RCF: 2951xg Rotor capacity: 8x100ml |
Max, speed: 4000rpm Max RCF: 2951xg Rotor capacity: 16×10/15ml (Optional) |
| Swing-out Rotor No.9 | Swing-out Rotor No.10 |
| Max, speed: 4000rpm Max RCF: 2951xg Rotor capacity: 24×10/15ml (Optional) |
Max, speed: 4000rpm Max RCF: 2951xg Rotor capacity: 32×10/15ml (Optional) |
| Swing-out Rotor No.11 | Swing-out Rotor No.12 |
| Max, speed: 4000rpm Max RCF: 2951xg Rotor capacity: 48×2-7ml (Blood collection tube) |
Max, speed: 4000rpm Max RCF: 2951xg Rotor capacity: 64x5ml (Blood collection tube) |
| Swing-out Rotor No.13 | Swing-out Rotor No.14 |
| Max, speed: 4000rpm Max RCF: 3040xg Rotor capacity: 4x250ml (Round bucket) |
Max, speed: 4000rpm Max RCF: 3040xg Rotor capacity: 4x250ml (Round bucket with biosafety lid) |
| Swing-out Rotor No.15 | Swing-out Rotor No.16 |
| Max, speed: 4000rpm Max RCF: 3040xg Rotor capacity: Auto uncap 64×2-7ml (Blood collection tube) |
Max, speed: 4000rpm Max RCF: 3040xg Rotor capacity: 4x250ml (Square bucket) 4x4x50ml Conical bottom,4x10x15ml Conical bottom |
| Swing-out Rotor No.17 | |
| Max, speed: 4000rpm Max RCF: 2057xg Rotor capacity: Micro-plate 2x2x96 holes |
|
