Features
-
Ambient temperature range :10℃~32℃.
-
Accurate Temperature control technology to make the temperature maintain -40℃~-86℃and accuracy 0.1 °C.
-
The single level optimization of auto cascade refrigeration system design, less refrigeration component for easy maintenance.
-
SPCC sprayed steel external material and 304 stainless steel inner chamber for friendly using and easy cleaning.
Safety
-
Build-in back-up battery to display temperature and to operate audible and visual alarm system for up to 72 hours without AC power.
-
Visual and audible alarm system:High/low temperature,Sensor error, Thermostat failure alarm,power failure alarm,door switch, ambient temperature alarm, condenser failure alarm, filter check alarm, voltage abnormal alarm, low battery alarm
-
Power failure protection: turn on delay of the cooling system when power failure,restart delay protection.
-
Keyboard lock, password protection to avoid set parameter randomly.
-
Wide available voltage range: 187V~242V.
Humanized design
-
4 casters with stopper for easy moving and fixation.
-
1 adjustable shelves for easy storing.
-
Removable condenser dust gauze convenient for cleaning and maintenance.
-
Removable inner door for user to defrost and clean.
-
Standard Independent Power Switch.
Special：
-
Patented technology, mixed refrigerant.
-
Standard remote alarm port
-
Cold storage box loading QTY:2400
-
MRNA vaccine can be stored:2400pcs
-
10 visual and audible alarms.
Main Technical Parameters
| Performance | Temperature Range | -40~-86°C |
| Ambient Temperature | +10~+32°C | |
| Controller | Microprocessor | |
| Display | Digital Display | |
| Refrigeration System | Compressor/Brand | 1/SECOP |
| Refrigerant | Mixed | |
| Cooling Type | Direct cooling | |
| Defrost Type | Manual | |
| Electrical Data | Power Supply(V/Hz) | 220~240V/50~60;115/60 |
| Capacity | 58L | |
| Rated Power(W) | 442 | |
| Electrical Current(A) | 2.67 | |
| Power Consumption | 5.6 kWh/24h | |
| Power failure alarm | 72H | |
| Loading Qty(20’/40’/40’H) | 21/43/43 | |
| Dimensions | Interior Size(W*D*H) | 330*453*410mm |
| Exterior Size(W*D*H) | 635*757*1212mm | |
| Package Size(W*D*H) | 730*845*1400mm | |
| N.t./G.t.(approx) | 115/155kg | |
| Alarm | High/Low Temperature | Y |
| Sensor Error | Y | |
| Power Failure | Y | |
| Door ajar | Y | |
| Ambient temp. | Y | |
| Condenser clean | Y | |
| Low battery | Y | |
| Filter screen check | Y | |
| Abnormal voltage | Y | |
| Thermostat failure | Y | |
| Accessories | Caster | 4 |
| Remote alarm port | Y | |
| Inner Door | 1(stainless steel) | |
| Shelf | 1(stainless steel) | |
| Test hole | 1/25MM | |
| Data looger | Optional | |
| CO2 back up system | Optional | |
| LN2 back up system | Optional | |
| Cold storage box loading | QTY 2400 | |
| MRNA vaccine can be stored | 2400pcs |
