Features
-
Accurate Temperature control technology to make the temperature maintain 2~8℃and increment 0.1℃.
-
Specially designed forced-air cooling system to ensure frost-free cabinet and good temperature uniformity.
-
Designed for ambient temperature 10~32℃with humidity below 95%.
-
Three layer toughened glass door with heater to avoid condensation.
-
Color spray steel plate inner chamber for friendly using and easy cleaning.
-
Wide available voltage range: 187V~242V
Safety
-
Safety door lock and controller setting password to prevent unauthorized access.
-
Build-in back-up battery to display temperature and to operate audible and visual alarm system for up to 8 hours without AC power.
-
Auto on/off cooling fan to prevent cold air from leaking out when the door is opening.
-
Visual and audible alarm system: High/low temperature, power failure, sensor error, door ajar
-
Power failure protection: turn on delay of the cooling system after power failure.
-
Controller error protection: the cooling system will remember the normal working cycle and keep working depending on this memory when controller or two sensor failed.
Humanized design
-
4 casters,and two with stopper for easy moving and fixation.
-
10 adjustable shelves for easy storing.
-
Special designed service-free drainage system, ensure no water in the cabinet.
-
Auto on/off LED light with manual switch on control panel.
-
Automatic spring back design of double heated glass door
-
Standard test hole for convenient installation of temperature recorder
Main Technical Parameters
Reliable control system: ±3°C
Forced-air cooling system, frost-free
Glass door with heater, condensation-free
Wide voltage design: 187V~242V available
4 visual and audible alarms
| Performance | Temperature Range | 2~8°C |
| Ambient Temperature | +10~+32°C | |
| Controller | Microprocessor | |
| Display | Digital Display | |
| Refrigeration System | Compressor | 1 |
| Refrigerant | R600a | |
| Cooling Type | Forced air cooling | |
| Defrost Type | Automatic | |
| Electrical Data | Power Supply(V/Hz) | 220/50~60; 115/60 |
| Rated Power(W) | 385 | |
| Electrical Current(A) | 2.3 | |
| Power Consumption | 5.75 kWh/24h | |
| Alarm | High/Low Temperature | Y |
| Sensor Error | Y | |
| Power Failure | Y | |
| Door ajar | Y | |
| Dimensions | Capacity | 656L |
| Interior Size(W*D*H) | 1100*454*1325mm | |
| Exterior Size(W*D*H) | 1240*630*1895mm | |
| Package Size(W*D*H) | 1335*710*2000mm | |
| N.t./G.t.(approx) | 166/184kg | |
| Loading Qty(20’/40’/40’H) | 13/27/27 | |
| Accessories | Caster | 4 |
| Light | LED | |
| Shelf | 10 | |
| Temp. Recorder Chart recorder | Optional | |
| Test hole | 1/25mm |
