Features
-
Adjustable temperature range 2-8℃
-
Microprocessor control, digital display, and temperature adjustment with an increment of 0.1℃ Large digital display screen
-
Temperature variation within ±3℃
-
Permanently lubricated cooling fan for safety and longevity
-
High efficiency specialty compressor with known field reliability
-
Forced- air cooling with optimized air distribution system designed
Safety
-
Build-in back-up battery to display temperature and to operate audible and visual alarm system for up to 8 hours without AC power.
-
Visual and audible alarm system:High/low temperature, thermostat failure alarm,power failure alarm, door ajar.
-
Power failure protection: turn on delay of the cooling system when power failure,restart delay protection.
-
Keyboard lock, password protection to avoid set parameter randomly.
-
Wide available voltage range: 187V~242V.
Humanized Design
-
Optimized space utilization design with multi – level and adjustable shelf height to accommodate storage requirement of pharmaceutical products of various kinds.
-
Standard with Auto on/off LED Interior light with manual switch on control panel.
-
Safety lock to prevent unauthorized access
-
4 casters with stopper and 2 adjustable feet for easy moving and fixation.
Main Technical Parameters
Reliable control system Inside temperature 2~8°C
Forced-air cooling system Frost-free
Service-free drainage system
Wide voltage range 187V~242V available
5 visual and audible alarms
| Performance | Temperature Range | +2~+8℃ |
| Ambient Temperature | 10~32°C | |
| Controller | Microprocessor | |
| Display | Digital Display | |
| Refrigeration System | Compressor | 1 |
| Refrigerant | R290 | |
| Cooling Type | Forced-air cooling | |
| Defrost Type | Frost free | |
| Electrical Data | Power Supply(V/Hz) | 220/50~60; 115/60 |
| Rated Power(W) | 240W | |
| Electrical Current(A) | 1.2 | |
| Power Consumption | 1.78kWh/24h | |
| Alarm | High/Low Temperature | Y |
| Power Failure | Y | |
| Door ajar | Y | |
| Thermostat failure | Y | |
| Dimensions | Capacity | 316L |
| Interior Size(W*D*H) | 540*425*1380mm | |
| Exterior Size(W*D*H) | 660*555*1915mm | |
| Package Size(W*D*H) | 710*640*1970mm | |
| N.t./G.t.(approx) | 92.5/100kg | |
| Loading Qty(20’/40’/40H) | 27/54/54 | |
| Accessories | Caster | 4 |
| Lamp | LED | |
| Door | 1/Glass door | |
| Shelf | 5 | |
| Test hole | 1/25mm | |
| Temperature recorder | Optional |
