Characteristics
Heating power and stirring speed is steplessadjustable.
With adjustable thermometer rack, stainlesssteel rods and the stir bar.
SH-(C) series: Ceramic Plate
SH-3D: Aluminium plate & Display controller
SH-3D(C): Ceramic plate&Display controller
Main Technical Parameters
| Model | SH-2A | SH-2B | SH-2 | SH-3A | SH-3B | SH-3D | SH-3 | |||
| SH-2A (C) | SH-2B (C) | SH-2 (C) | SH-3A (C) | SH-3B(C) | SH-3D(C) | SH-3 (C) | ||||
| Function | Max. Volume (ml) | – | 2000 | 2000 | – | 5000 | 5000 | 5000 | ||
| Speed (r.p.m) | – | 100~2000 | – | 100~2000 | ||||||
| Working time | Continuous | |||||||||
| Minimum revolution (r.p.m) | – | 100 | 100 | – | 100 | 100 | 100 | |||
| Max.Temp.（℃） | 380 | – | 380 | 380 | – | 380 | 380 | |||
| Structure | Exterior | Cast aluminium, Surface spraying | ||||||||
| Plate size(mm) | 120×120 | 170×170 | ||||||||
| Driving mode | – | Motor | – | Motor | ||||||
| Motor power (W) | – | 10 | – | 20 | ||||||
| Heating Power(kW) | 0.18 | – | 0.18 | 0.5 | – | 0.5 | 0.5 | |||
| Stir bar | – | PTFE | – | PTFE | ||||||
| Controller | Continuous operation | Yes | ||||||||
| Setting mode | Scale | |||||||||
| Speed display mode | – | Scale | – | Scale | ||||||
| Timer | No | |||||||||
| Operation function | No | |||||||||
| Temp. Sensor | No | Yes | No | |||||||
| Specification | Exterior size (W*L*H)(mm) | 200×120×90 | 265×185×190 | |||||||
| Packing size (W*L*H)(mm) | 250×180×120 | 280×210×220 | ||||||||
| Plate size（mm） | 120×120 | 170×170 | ||||||||
| Plate load | 3KG | 10KG | ||||||||
| Power supply（50/60Hz）Current rating | 110V or 220V | |||||||||
| NW/GW (kg） | 1.9/3 | 1.9/3 | 1.9/3 | 2.2/3.4 | 2.2/3.4 | 2.2/3.4 | 2.2/3.4 | |||
