Feature
Automatically calculate RCF,RPM and RCF switching freely.
Can store 40 groups of program and with shortcut key.
Up to 10 level acceleration/deceleration with Linear drive.
With five groups of user-defined preset programs that can be called by one key.
Long press the start/instantaneous key to realize instantaneous centrifugation.
Two modes can be set: start timing/ arrival revolution timing.
Imported energy-efficient ECO friendly refrigeration system.
Microcomputer control with HD large LCD touch screen,driven by AC frequency conversion brush-less motor.
Full steel inner cavity protective cover
Over speed,over heat,unbalance etc protections and ensure safe operation.
With accompanying professional tools.
The front of the fuselage is designed with an operation SOP guide map, which makes it easier and more standard for laboratory personnel to use the instrument.
Equipped with rotor lid that can be quickly locked.
Ergonomic, low opening height, close the centrifuge lid with one time press.
Special noise reduction system.
Main technical parameters
Technical Parameter:
| Model | FGTR116C |
| Max Speed | 16500rpm |
| Max RCF | 21615×g |
| Max Capacity | 12×5ml |
| Timer | 1s～99h59min59s |
| Revolutions/min | ±10r/min |
| Temp Range | -20℃~40℃ |
| Temp Accuracy | ±1.0℃ |
| Voltage | AC 220±22V 50Hz 10A |
| Power | 550W |
| Noise Level | ≤ 60dB（A） |
| Size | 315×475×310(mm) |
| Net Weight | 36kg |
| Automatic Rotor Identification | No |
Rotor Parameters
| Angle Rotor No.1 | Angle Rotor No.2 | Angle Rotor No.3 |
| Max, speed: 16500rpm Max RCF: 20880xg Rotor capacity: 16×1.5/2.0ml |
Max, speed: 16000rpm Max RCF: 17344xg Rotor capacity: 12×5ml |
Max, speed: 15000rpm Max RCF: 21615xg Rotor capacity: 24×1.5/2.0ml |
| Angle Rotor No.4 | Angle Rotor No.5 | Angle Rotor No.6 |
| Max, speed: 15000rpm Max RCF: 14866xg Rotor capacity: 4×8×0.2ml PCR Row |
Max, speed: 14000rpm Max RCF: 15032xg Rotor capacity: 8×8×0.2ml PCR Row |
Max, speed: 12000rpm Max RCF: 13845xg Rotor capacity: Capillary rotor 24 hole |
