• The installation of the glass plate in just 15 seconds, and does not need the knob, fast and convenient.
• With a gel casting in original position, no need to move glasses from gel making to elctrophoresis running. It is more convenient to observe gel preparing through both sides of the glasses.
• High transparent polycarbonate material injection molding, impact resistance, high temperature resistance, corrosion resistance.
• Safety cover open button design, convenient opening the cover.
• With the background color, easy to be observed in the sample adding and electrophoresis process.
• Abundant buffer not only guarantees cooling effects, but also keeps the pH Value stable during the whole experiment process.
• Auto-switch-off when the lid is removed.
Main Technical Parameters
| Glass plate size(W×L) | Gel Size (W×L) | Gel thickness | Gel amount | Sample volume | Buffer Volume |
Dimension (L×W×H) | Netweight |
| 100×100 mm | 82×88 mm | 0.75、1.0、1.5 (mm) |
1～2 (pieces) |
(0.75mm)11、15 wells;(1.0mm)11 、15wells (1.5mm)11、15wells |
~750 (ml) |
150×120×115 (mm) |
1.5(kg) |
