Features
-
Two-compressor cascade refrigeration system specially designed for cryogenic applications.
-
Wide available voltage range: 187V~242V.
-
Ambient temperature :10℃~32℃.
-
Accurate Temperature control technology to make the temperature maintain -40℃~-86℃and accuracy 0.1℃.
-
Removable heat exchanger, almost all of the relevant components of the cooling system could be maintained and replaced.
-
Realize historical temperature curve query and download
-
Independent switch, standard USB port, easy to download data
-
HC refrigeration system, energy saving 50%
-
VIP II PLUS technology, special narrow design for entering elevators.
Safety
-
Build-in back-up battery to display temperature and to operate audible and visual alarm system for up to 72 hours without AC power.
-
Visual and audible alarm system: High/low temperature,Power failure,Abnormal voltage,Sensor error,Filter screen check,Low battery,Condenser clean,High ambient temperature,Door ajar alarm
-
Power failure protection: turn on delay of the cooling system when power failure,restart delay protection.
-
Keyboard lock, password protection to avoid set parameter randomly.
-
Special noise reduction design.
Humanized design
-
4 casters with stopper for easy moving and fixation.
-
standard 25mm test hole for easy connecting to temperature monitoring systems.
-
3 adjustable shelves for easy storing.
-
Visual and audible alarm and all alarm can be through reserved for remote alarm port remote alarm
-
Removable condenser front cover convenient for cleaning and maintenance.
-
With the function of hand-written artboard, convenient for customers to record temporary information.
-
With A4 paper slot function, convenient for customer management and equipment related information
Special:
-
Patented technology, HC refrigerant.
-
Standard remote alarm port
-
10 visual and audible alarms.
Main Technical Parameters
| Performance | Temperature Range | -40~-86°C |
| Ambient Temperature | +10~+32°C | |
| Controller | Microprocessor | |
| Display | Digital Display | |
| Refrigeration System | Compressor/Brand | 2/SECOP |
| Refrigerant | HC | |
| Cooling Type | Direct cooling | |
| Defrost Type | Manual | |
| Electrical Data | Power Supply(V/Hz) | 220~240V/50~60;115/60 |
| Rated Power(W) | 815 | |
| Electrical Current(A) | 7 | |
| Power Consumption | 12kWh/24h | |
| Power failure alarm | 72H | |
| Loading Qty(20’/40’/40’H) | 12/24/ 24 | |
| Dimensions | Capacity | 588L |
| Interior Size(W*D*H) | 606*738*1310mm | |
| Exterior Size(W*D*H) | 880*1080*2000mm | |
| Package Size(W*D*H) | 975*1140*2200mm | |
| N.t./G.t.(approx) | 307/368kg | |
| Alarm | High/Low Temperature | Y |
| Sensor Error | Y | |
| Power Failure | Y | |
| Door ajar | Y | |
| Ambient temp. | Y | |
| Condenser clean | Y | |
| Low battery | Y | |
| Filter screen check | Y | |
| Abnormal voltage | Y | |
| Thermostat failure | Y | |
| Accessories | Caster | 4 |
| Remote alarm port | Y | |
| Inner Door | 2(stainless steel) | |
| Shelf | 3(stainless steel) | |
| Test hole | 1/25MM | |
| Chart recorder | Optional | |
| CO2 back up system | Optional | |
| LN2 back up system | Optional | |
| Cold storage box loading QTY | 400 | |
| MRNA vaccine can be stored | 40000pcs |
