Features
-
Chemically stable, CFC-free, commercially available and environmentally,safe refrigerant.
-
High density foam insulation for rigidity and stable storage temperature.Microprocessor control, digital display adjustable temperature rage: -30℃–40℃.
-
LED digital display for clear observation.
-
Wide voltage tolerance design with applicable voltage range of 187~242 V/AC.
Safety
-
Multiple malfunction alarms including high and low temperature , sensor error
-
Two types of alarm indications: audible buzzing and visible flashing light.
-
Door lock for storage safety Lockable High Quanlity DrawersHumanized design
-
Upright side door with build-in handle for easy-opening; limit door hinge to prevent collision when door open .
-
Lockable caster design for customer to move as needed .
-
Controller password protect function to avoid change running parameter randomly.
Special：
-
7 drawers easy to sort and store different types of samples;
-
Environmentally friendly refrigerant;
-
Easy-to-clean sprayed steel plate material;Not easy to adhere to dust
Main Technical Parameters
| Performance | Temperature Range | -30~-40°C |
| Ambient Temperature | +10~+32°C | |
| Controller | Microprocessor | |
| Display | Digital Display | |
| Refrigeration System | Compressor/Brand | 1/CUBIGEL |
| Refrigerant | R290 | |
| Cooling Type | Direct cooling | |
| Defrost Type | Manual | |
| Electrical Data | Power Supply(V/Hz) | 220~240V/50~60;115/60 |
| Rated Power(W) | 185 | |
| Electrical Current(A) | 1.6 | |
| Power Consumption | 3 kWh/24h | |
| Power failure alarm | 8H | |
| Loading Qty(20’/40’/40’H) | 24/54/54 | |
| Dimensions | Capacity | 278L |
| Interior Size(W*D*H) | 480*415*1460mm | |
| Exterior Size(W*D*H) | 670*640*1695mm | |
| Package Size(W*D*H) | 725*665*1850mm | |
| N.t./G.t.(approx) | 79/104.5kg | |
| Alarm | High/Low Temperature | Y |
| Sensor Error | Y | |
| Power Failure | / | |
| Door ajar | Y | |
| Thermostat failure | Y | |
| Condenser clean | / | |
| Accessories | Caster | 4 |
| Remote alarm port | / | |
| Inner Drawers | 7 | |
| Shelf | 4 | |
| Test hole | 1/25MM | |
| Data logger | Optional |
